WatchGuard XTM 26 Wireless
Extensible Threat Management for Growing Businesses

WatchGuard XTM 26 Series Overview:

WatchGuard XTM 25 and 26 appliances deliver a new class of performance-driven security. Network protection is stronger than ever, with full HTTPS inspection, VoIP support, and optional application control. Includes five 1GbE ports for faster link speeds, and wireless models have dualband 802.11/n technology for greater wireless speed and responsiveness. An XTM 25 or 26 appliance can be used as a standalone security solution for a small business, and makes an ideal endpoint for connecting a secure VPN tunnel back to a WatchGuard XTM network.

With a WatchGuard® XTM 25 and 26 Series appliance, your network is:

Secure:

• Application-layer content inspection recognizes & blocks threats that stateful packet firewalls cannot detect.
• Wide-ranging proxy protection comes from robust security on HTTP, HTTPS, FTP, SMTP, POP3, DNS, TCP/UDP.
• Security subscriptions boost protection in critical attack areas for complete unified threat management: blocking spam, controlling dangerous web surfing, preventing network intrusions, and stopping viruses, spyware, and other malware at the gateway.
• Optional Application Control keeps unproductive and dangerous applications off-limits.

Efficient:

• Interactive, real-time monitoring and reporting – at no extra charge – give an unprecedented view into network security activity, so you can take immediate preventive or corrective actions.
• Intuitive management console centralizes configurations and streamlines remote management.
• Five 1GbE interfaces allow faster link speeds, which is particularly useful for trusted LAN.
• Drag-and-drop Branch Office VPN setup – three clicks and your remote office is connected.

Flexible:

• Call setup security for VoIP means you don’t need to “wire around the firewall” to take advantage of the big cost savings that VoIP can generate.
• WAN and VPN failover provide redundancy for increased reliability.
• Multiple VPN choices deliver flexibility in remote access. Includes IPSec, SSL, and support for iOS devices such as iPhone, iPad, and iPod touch.
• Advanced networking features, like transparent bridge mode and dynamic routing support, allow you to add security without needing to change existing network infrastructure.

Wired or Wireless - Your Choice:

• Wireless models include optional dual-band 802.11/n technology for much more responsive wireless network connection and expanded range. Allows users to access 2.4 GHz or less crowded 5 GHz band.
• Multiple security zones give administrators precise control over Internet access privileges for different user groups.
• Wireless guest services segment the Internet for customers/guests.

Capable:

• Multi-layered, interlocking security protects the network.
• Secure remote connectivity keeps mobile workforce productive.
• Intuitive, centralized management gives you the control you need to manage efficiently.
• Choice of wired or wireless models to suit your specific business requirements.
• Monitoring and reporting tools, included at no extra cost, support industry and regulatory compliance, with drill-down functions that make it easy to pinpoint specific activities.

Features:

Detailed Specifications:

Powered by Fireware® XTM and XTM Pro

XTM 2 Series appliances can be upgraded to the Pro version of the Fireware XTM operating system with a simple License purchase***. Advanced networking features include:

*Throughput rates will vary based on environment and configuration
** All XTM 2 Series appliances are available in wireless versions under the model numbers XTM 21-W, XTM 22-W, XTM 23-W, XTM-25-W, and XTM-26-W
*** The XTM-23 and XTM-23-W Series ship with Fireware XTM Pro series installed.

Compare Models:

WatchGuard Model	XTM 21/21-W	XTM 22/22-W	XTM 23/23-W	XTM 25/25-W	XTM 26/26-W
Ideal For	Remote offices, small businesses that need and easy-to-manage solution at a great price. Available in wired and wireless models.			Remote offices, small business, wireless hotspots that want an affordable, all-in-one security solution. Available in wired and wireless models.
Hardware
Model Upgradeable			N/A		N/A
Interfaces	3: 10/100/1000 and 3:10/100	3: 10/100/1000 and 3:10/100	3: 10/100/1000 and 3:10/100	5 1GbE	5 1GbE
Security
Application Proxies	HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323, TFTP
Intrusion Prevention (DOS, DDOS, PAD, port scanning, spoofing attacks, address space probes, and more)
Wireless Models Only	802.11b/g/n, WPA, WPA2, WEP, Wireless Guest Services
User Authentication with transparent Windows authentication
Performance
Firewall Throughput**	110 Mbps	150 Mbps	195 Mbps	110 Mbps	350 Mbps
VPN Throughput**	35 Mbps	55 Mbps	55 Mbps	35 Mbps	55 Mbps
XTM Throughput**	18 Mbps	40 Mbps	40 Mbps	20 Mbps	30 Mbps
Concurrent Sessions* (bi-directional)	10,000	20,000	30,000	10,000	30,000
VPN Tunnels
Branch Office VPN Tunnels (Max.)	5	20	50	10	40
Mobile VPN with SSL (Incl/Max)	1 / 11	5 / 25	55	1 / 11	1 / 25
Mobile VPN with IPSec Client Licenses (Bundled)	1	5	5	5	5
Mobile VPN with IPSec Tunnels (Max.)	11	25	55	10	40
VPN Authentication
Management
Mobile VPN IPSec (incl/max)	1-device WatchGuard System Manager license included with purchase.
Networking Features
Dynamic NAT
Static NAT
One to One NAT
VLAN	20, upgradeable to 50 with Fireware® XTM Pro upgrade	20, upgradeable to 50 with Fireware® XTM Pro upgrade	50	20, upgradeable to 50 with Fireware® XTM Pro upgrade	20, upgradeable to 50 with Fireware® XTM Pro upgrade
Policy-Based Routing	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro		Optional with Fireware XTM Pro	Optional with Fireware XTM Pro
WAN Failover	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro		Optional with Fireware XTM Pro	Optional with Fireware XTM Pro
Multi-WAN Load Balancing	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro		Optional with Fireware XTM Pro	Optional with Fireware XTM Pro
Server Load Balancing	N/A	N/A	N/A	N/A	N/A
Traffic Management/QoS
High Availability Active/Active or Active/Passive	N/A	N/A	N/A	N/A	N/A
Dynamic Routing	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro	Optional with Fireware XTM Pro
VoIP (SIP and H.323)Support
Networking Features
Application Control	Optional	Optional	Optional	Optional	Optional
Reputation Enabled Defense	Optional	Optional	Optional	Optional	Optional
spamBlocker with Virus Outbreak Detection	Optional	Optional	Optional	Optional	Optional
Gateway AntiVirus/ Intrusion Prevention Service (IPS)	Optional	Optional	Optional	Optional	Optional
WebBlocker with HTTPS URL filtering	Optional	Optional	Optional	Optional	Optional
LiveSecurity® Service	1-year and 3-year subscriptions available

*Concurrent sessions here represent the number of bi-directional connections.
**Throughput rates will vary based on environment & configuration.

Product Views:

Options and Upgrades:

Turn your WatchGuard XTM security appliance into a complete threat management solution with a WatchGuard Security Suite.

Documentation:

Download the WatchGuard XTM 25 and 26 Series Datasheet (PDF).
